XEV Megawatt Charging System

Step into the future of heavy-duty electric transportation with XEV's Megawatt Charging System—engineered for performance, flexibility, and sustainability.

Revolutionizing heavy-duty electric transportation, the XEV Megawatt Charging System (MCS) is designed to deliver power levels exceeding 1 MW, making it the ultimate solution for electric truck charging. This system paves the way for a cleaner, quieter, and more sustainable world, as part of a collaborative ecosystem shaping the future of transport.

Key Components of the XEV Megawatt Charging System

  1. XEV Mega Satellite with MCS:Megawatt-level charging for electric trucks.
  2. XEV Mega Satellite with High-Power CCS:High-power CCS charging for electric trucks.
  3. XEV Power Unit:Provides up to 1.2 MW of total charging power.
Technical Specifications
  • Power: Up to 1.2 MW
  • Current: 1,500 A
  • Voltage Range: 200 – 1,250 VDC*

Ultra High-Power Charging Features:

  • Delivers +1,500 A and peak power of up to 1.2 MW.
  • Compatible with XEV Mega Satellite, featuring MCS and high-power CCS options.
MCS
  • Power: Max. 1.2 MW
  • Current: 1,500 A
  • Voltage Range: 200 – 1,250 VDC*
High-Power CCS
  • Power: Max. 560 kW
  • Current: 700 A
  • Voltage Range: 200 – 1,250 VDC* (*Limited to 920 VDC during the initial development phase.)

Driving the Transition to MCS

  1. Increased Power for CCS: To facilitate the transition to MCS, current CCS power levels for heavy-duty vehicles are being elevated, enabling the market to gradually adopt full MCS functionality.
  2. Dual Strategy: Coexistence of MCS and high-power CCS is essential for OEMs and EV supply manufacturers to advance the shift toward zero-emission road transport.
  3. Flexibility and Dynamic Power Distribution: Unused power from the MCS can be dynamically allocated to high-power CCS outputs within the same system, ensuring maximum efficiency and supporting the transition to widespread MCS adoption.

Configuration Highlights

  1. Proven Technology: The first iteration of the XEV Megawatt Charging System includes a XEV Mega Satellite and peak power of 1.2 MW, based on XEV's advanced charging technology.
  2. Maximum Flexibility: The Mega Satellite supports both MCS and high-power CCS connections, enabling seamless dynamic power sharing between outputs.
  3. Upgradability: Existing XEV systems can be upgraded to MCS by integrating two 600 kW XEV Power Units.
